Residential steel building is lightweight and high-strength. For buildings of the same weight, the steel structure has a small cross-section and a large net height, which can save building height. The number of layers of steel structure is more than that of concrete, which not only increases the building area, but also brings good economic benefits.

• What are the advantages of Residential steel building?

• What raw materials should be used for the walls of Residential steel building?

• What is the roof system of Residential steel building?

What are the advantages of residential steel building?

1. Superior seismic performance

Compared with traditional residential structures, residential steel building is a flexible structure and has a lighter weight. Therefore, buildings with the same fortification intensity and the same site will bear less seismic force, and the earthquake disaster caused by them will be weakened accordingly. The use of steel in the earthquake zone structural housing will reduce casualties and property losses, with considerable comprehensive benefits.

2. Flexible layout and increased effective use area

Residential steel building adopts steel structure, which can realize large span under the premise that the cross-section is not too large, which makes the building function very flexible and can be flexibly arranged according to the needs of residents, which is conducive to meeting the needs of modern homes and adapting The needs of the modern housing market. Moreover, the steel structure is adopted, the cross-section of the beams and columns is small, and the use area of the residents is increased at the same time.

What raw materials should be used for the walls of residential steel building?

Residential steel building's steel frame system, steel frame-support system, steel frame-concrete core tube (shear wall) system outer walls can be filled with small concrete block walls, autoclaved lightweight aerated concrete slabs, and prefabricated reinforced concrete walls Board, steel wire mesh frame polystyrene sandwich panel, fiber cement external wall hanging panel, polyurethane composite external wall panel, metal surface embossed composite panel, etc. The inner wall can be made of glass fiber strong gypsum hollow board, fiber cement board infusion (foam concrete) wall, light composite wall board, etc.

What is the roof system of Residential steel building?

1. The flat roof of the residential steel building adopts steel beams (I-beam, C-shaped steel), prefabricated reinforced concrete roof panels, and thermal insulation and waterproof layer.

2. The sloping roof of residential steel building adopts portal frame, truss, light steel keel truss (bracket), I-shaped (or C-shaped) and steel purlin, colored cement tile, colored steel plate tile and colored asphalt tile roof. Thermal insulation and waterproof layer should also be used in the slope roof. The thickness of the insulation layer is determined by thermal calculation and meets the requirements of energy-saving design standards.

It is an important choice in residential building construction. A good Residential steel building starts with the best engineering staff, and Qingdao Xinguangzheng Steel Structure Co., Ltd. is always ready to help you meet your technical and practical requirements.

The development of residential steel building conforms to the industrial technology policy of protecting arable land and saving energy, and is also one of the production methods for realizing residential industrialization. The development of steel structure housing is the general trend.

• What is the layout of the residential steel building?

• What issues should be paid attention to when designing residential steel building?

• Why pay attention to the design of residential steel building?

What is the layout of the residential steel building?

Residential steel building's column grid layout should be regular, and it is advisable to use residential units or sleeves as the unit to achieve modularity. The modular flat connection, wrong connection and symmetrical concave (convex) connection and other splicing adapt to changes in the overall layout.

When the residential steel building module adopts small column net, it should be combined with the floor and pipeline design; when the module adopts large column net, the facility pipeline should be designed as a fixed-positioned tube bundle, and the electrical and communication lines can be along the cavity and skirting of the partition wall. , Mirror hanging line or top line arrangement.

The kitchen and bathroom are located close to the concrete core tube or concrete shear wall, and avoid steel structure load-bearing components to facilitate the fire prevention and anti-corrosion treatment of steel components.

Vertical pipelines are centrally arranged in pipeline wells or pipeline walls, or installed on site using factory prefabricated tube bundles.

The toilet is drained on the same floor. Use a double pipe system for centralized heating, and use a temperature control valve and a heat meter. Use the equipotential characteristics of the steel structure to make a natural ground connection.

What issues should be paid attention to when designing residential steel building?

Residential steel building should be dominated by construction and design, and other professions should interact closely with each other. In addition to following the general principles of residential building design, residential steel building must also focus on solving:

(1) How to make use of the advantages of steel structure? The beam span can be enlarged, the bays can be more flexible, and more space can be created for residents. But how to avoid the flatness and monotonous facade of the building caused by the steel structure.

(2) It is necessary to solve the fire protection and anti-corrosion problems of steel structure residential buildings. Especially in rainy areas, the quality of anti-corrosion and anti-rust work directly affects the promotion of steel structure housing.

Why pay attention to the design of residential steel building?

The cost of residential steel building is the most concerned issue of real estate developers. Steel structure residences should be positioned in middle and high-end residences. Steel structure residences are a systematic project. Management and coordination should be strengthened from design, manufacturing, transportation, installation, maintenance and management, so as to reduce costs and improve overall economic benefits. the goal of.

Qingdao Xinguangzheng Steel Structure Co., Ltd. strives to provide top-quality residential steel buildings with reasonable prices, efficient production time, and the most professional customer service.

Generally speaking, steel building accessories include: steel column systems, steel beam systems, support systems, connection systems, purlin systems, and brace stairs. This is a part and an indispensable part of every steel structure project.

• What are the advantages of using Steel building accessories?

• How to paint Steel building accessories?

• What may cause the deformation of Steel building accessories?

What are the advantages of using steel building accessories?

1. Health

In the process of using steel building accessories, dry construction is used to reduce the environmental pollution caused by waste. The Steel building accessories of the house can be 100% recycled, and most of other supporting materials can also be recycled, which is in line with the current awareness of environmental protection; All materials are green building materials, which meet the requirements of ecological environment and are conducive to health.

2. Comfort

The wall is built by steel building accessories, and the high-efficiency energy-saving system is adopted, which has breathing function and can adjust the dry humidity of indoor air; The roof has ventilation function, which can form a flowing air room over the house to ensure the ventilation and heat dissipation requirements inside the roof.

3. Fast

All dry operations shall be carried out without being affected by environmental seasons. A building of about 300 square meters only needs 5 workers and 30 working days to complete the whole process from foundation to decoration.

4. Environmental protection

Materials can be 100% recycled, truly green and pollution-free.

5. Energy saving

All adopt high-efficiency and energy-saving walls, with good thermal insulation, heat insulation and sound insulation effects, which can reach the energy-saving standard of 50%.

How to paint steel building accessories?

(1) Method of painting construction:

There are two commonly used methods in Steel building accessories maintenance engineering, namely, painting method and spraying method.

(2) Matters needing attention:

1) The base layer should be thoroughly cleaned before painting, and kept dry, and the first coat of primer should be applied as soon as possible within no more than 8h.

2) When applying the primer, choose an appropriate painting method according to the size of the area.

3) When painting the top coat, it should be painted according to the color and variety requirements of the design, and the painting method is the same as the primer painting method.

4) Painting environment

5) The thinner should be used correctly.

What may cause the deformation of steel building accessories?

(1) The actual dynamic load of steel building accessories exceeds the maximum load (commonly known as "overload") allowed during the design of the steel structure.

(2) Bearing the impact of dynamic load for a long time.

(3) The impact of natural disasters (such as earthquakes) or uneven settlement of foundations.

(4) Improper use and maintenance or breakage of steel building accessories due to mechanical damage and withdrawal from work, resulting in an abnormal deformation of the steel structure due to unbalanced forces.

Qingdao Xinguangzheng Steel Structure Co., Ltd. is known for high precision Steel building accessories. And you can connect them.

Introduction for Low Price Construction Material Steel Structure Showroom Building Metal Mall Design

Aruba exhibition hall project is a renewal project of Aruba stadium customers, with a building area of 1585 square meters. The exhibition hall is a two-story frame structure, and the warehouse is a portal steel frame structure. Some walls of the exhibition hall are made of glass curtain wall and others. The storehouse is made of cement foam board, and the roof is a polyurethane composite board.

Project location: Aruba

Area: 1585 square meters

Span: 127m

Eaves height: 8.4m

Number of floors: 2

Wind speed: 148km / h

Shapes: Framing

Steel consumption: 92t

Name	Low Price Construction Material Steel Structure Workshop Building Metal Factory Shed Design
Material	Q235B,Q345B galvanized or painted steel
Main frame	H-section steel column and steel beam
Purlin	C/ Z- section steel purlin
Roof and wall	a) Color-coated corrugated steel sheet, b) Rock Wool Sandwich Panels, c) EPS Sandwich Panels, d) Glass wool Sandwich Panels, e) PU sandwich panel
Door	a)Rolling up door, b)Sliding door
Window	PVC /Steel or Aluminum Alloy frame window
Down spout	Round PVC pipe
Usage	All kinds of industrial workshop, warehouse, poultry shed, supermarket, hangar, etc
Service life	50Years

Detail Information

Roof with a single layer of galvanized steel plate sea blue crown Island, its structure and technical requirements are as follows:

1.V820 type 0.50mm thick galvanized roof panel (sea blue) crown Island

2.75mm thick glass wool with aluminum foil

3.200 * 200 coated steel mesh

4.Q235B C-type steel roof purlin

5.Q345B steel beam

Wall:

1.YX-840 plate type 0.40mm thick galvanized wall panel white gray crown Island

2.Q235B C steel wall purlins

3.Q345B steel column

Paint coating:

1. Shot blasting, rust level Sa2.5

2. In the gray anti-corrosion primer two, each 30 um

Other:

1. Roof panel - sea blue

2. Wall panel - white gray

3. Steel components - medium gray

Introduction of Pakistan Prefabricated Steel Structure Construction Cola Workshop:

Project Area: 23408 sqm

Project Usage：Pakistan Cola workshop

Project Location: Lahore, Pakistan

Project weight of steel structures： 760 tons.

Project Detail:

Wall & Roof：0.5mm galvanized steel sheet +50mm glass wool+0.4mm galvanized steel sheet.

Span: Multi-Span 100m and 50m

Total Height: 12m



Project picture of Pakistan Prefabricated Steel Structure Construction Cola Workshop :



Company information

A brief introduction to you about our company first, then you can contact me if there is suitable project in the future.

1200 workers, 360000 ㎡ non-dust workshop, 25 years experience, CE, ISO9001, ISO9712, ISO3834, BV, SGS certificated, one hour reach Qingdao port, our company, as a manufacture, this is how we keep good quality and competitive prices for global valued customers.

We provide steel building design, farm house design, manufacture and installation service.

The main structure of the commercial steel building can be installed simultaneously with the wall panel. The main structure and the wall panel are fixed by embedded parts and connectors, which is convenient for installation. It only needs to be hoisted in place, connected and fixed, and the three links of joint treatment are not required. No need for secondary grouting, and has the advantages of short construction period, high assembly rate, good integrity, and good wind pressure resistance.

What are the welding sequence and process parameters of commercial steel building typical nodes?

(1) When the sides of the upper and lower columns without ear plates are symmetrically welded to 1/3 of the plate thickness by two welders on both sides, cut off the ear plates.

(2) Then two welders are symmetrically welded on both sides to 1/3 of the plate thickness on the side where the ear plate is cut off.

(3) Two welders will be responsible for the welding of two adjacent sides.

(4) The joints of the weld bead between every two layers should be staggered with each other, and the weld bead joints welded by two welders should also pay attention to the stagger of each layer. Pay attention to the temperature between the layers during the welding process.

(5) Welding process parameters:

CO2 gas shielded welding: wire diameter Φ1.2mm, current 280～320A, welding speed 350～450mm/min

Extending length of welding wire: about 20mm, gas flow rate 25～80L/min,

Voltage 29～34V, interlayer temperature 120～150℃

What points should be paid attention to when installing commercial steel building?

We must prefabricate and assemble commercial steel building steel components on the steel platform in accordance with the installation sequence and process requirements, and ensure the quality of welding production.

The spacing between the splicing seam of the splicing flange plate and the splicing seam of the web plate of the section steel should be greater than 200 mm. The splicing length of the flange plate shall not be less than 2 times the plate width; the splicing width of the web shall not be less than 300 mm, and the length shall not be less than 600 mm.

In order to facilitate the welding of commercial steel building and ensure the welding quality, try to weld the reinforcement plates, connecting plates, backing plates, and overhanging beams (beams) on the columns and beams on the ground steel platform according to the dimensions of the construction drawings.

In addition to the fabrication and assembly of steel components prefabricated on the steel platform according to the construction drawings and specifications, the process and installation dimensions of the commercial steel building on-site installation should also be considered.

What is the social significance of commercial steel building?

The construction of commercial steel building has trained a new generation of construction and installation industrial workers. Factory production and mechanized installation avoid the high dependence of the traditional construction industry on labor, moderately reduce the impact of high labor costs brought on by the aging of the global population on the development of the industry, and predictably cultivate a new generation of construction and installation industry workers. It is of far-reaching significance to the sustainable development of the construction industry.

Qingdao Xinguangzheng Steel Structure Co., Ltd. has focused on the development and production of commercial steel buildings for several years. And it commits to provide perfect service for every customer from all over the world.

Introduction of Algerian layer house building with equipment

Project equipment system：4 rows of 5-layer cage nets

Project building feeding quantity：34800 layers

Project detail: On the basis of the customer's civil chicken house, Xinguang is transformed into a modern chicken house. In terms of animal husbandry equipment and plant, the company has a professional technical research and development team, each kind of equipment designed is more suitable for animal needs, so that animals can enjoy five-star treatment. The mode of "intelligent + intelligent equipment" that we have constructed makes farming easy and simple.
